FEATURES:
●Perfect introduction to metal turning.
● Small and light weight, fits anywhere.
● Cast iron and steel construction giving great rigidity.
●Electric variable speed. Over-load protection.
●Inside leadscrew.Manual or powered leadscrew feed.
|
Model No. |
TN140V x 250 |
|
Item No. |
|
|
Swing over bed |
140 mm |
|
Distance between centers |
250 mm |
|
Hole through spindle |
10 mm |
|
Spindle taper |
MT2 |
|
Tailstock taper |
MT1 |
|
Spindle speed |
100-2000 ±10% rpm |
|
Cross slide travel |
50 mm |
|
Compound travel |
- |
|
Motor output power |
150 W |
|
Range of metric threads |
0.5-1.25 mm (5 thread pitches) |
|
Range of inch threads |
16-24 TPI (5 thread pitches) |
|
Overall dimension (LxWxH) |
620x330x220 mm |
|
Weight (Net/Gross) |
23/32 kg |
|
Packing size (LxWxH) |
690x350x330 mm |
|
Standard Accessories |
Optional Accessories |
|
3 jaw chuck (80mm) |
3 jaw chuck (80mm) |
|
MT1 center |
MT2 center |
|
Wrench set |
Change gear set |
|
Oil can |
Wrench set |
|
|
Oil can |
|
|
3 jaw chuck (80mm) |
|
|
MT2 center |
