Model No.

M6136D

    Item No.

　Specifications

　Table size

1320 x 360 mm

　Table travel (X,Y)

1000 x 300 mm

　Knee travel

400 mm

　Tabel feed speed range (X)

22~420 mm/min.

　Table feed speed range (Y)

22~393 mm/min.

　Knee feed speed range

10~168 mm/min.

　T-slot

3 x 14 - 95 mm

　Ram travel

880 mm

　Distance from spindle nose to table

0~400 mm

　Distance from spindle axis to ram

175 mm

　Spindle taper

ISO50

　Step of spindle speeds

12

　Range of spindle speeds

58 ~ 1800 rpm

　Spindle motor

4 kw

　Distance from vertical spindle to column

－

　Overall dimension

2070 x 2050 x 1950 mm

　Net weight

2200 kg
